FO splice box, 1U, equipped, 1x32 Splice cassette, colored pigtails, couplings

Name: FO splice box 1U equipped 1x32 Splice cassette colored pigtails couplings
Brand: Geehe or OEM or ODM
Price: 1 USD

Brand Name : Geehe or OEM or ODM

Model Number : Fiber Optic PLC Splitter

Certification : ROHS, REACH, UL, ISO

Place of Origin : Wuhan, China

MOQ : 10 PCS

Price : Price Negotiation

Payment Terms : T/T, Western Union, L/C

Supply Ability : 10,000 pcs per month

Delivery Time : 7-10 days

Packaging Details : Blister Box or Carton Box

Product : Fiber optic patch panel

Fiber Type : Corning G657A or G652D

Configuration : 1X32~2X64

Height Units : 1U / 2U

Insertion Loss : 15.7~16.7dB, 20.5~21dB

Return Loss : UPC≥55, APC≥65

Uniformity : 1.5 / 2.0 dB

Maximum Input PowerLength : 250mW

Input Connector : FC/LC/SC/ST/MPO, or Customized

Output Conector : FC/LC/SC/ST/MPO, or Customized

Operation Wavelength : 1260~1650

Port Wavelength Range : 1310±20/1490±10/1550±20

Operating Temperature : -40~+85 ° C

Storage Temperature : -40~+85 ° C

Contact Now

FO splice box, 1U, equipped, 1x32 Splice cassette, colored pigtails, couplings

Description
The GEEHE fiber optic splice boxes have a solid and compact design and ensure the easy transition between fiber optic installation cables to duplex or breakout cables. The simple installation and optimal protection of the glass fibers in the full metal housing are just some of the advantages of these splice boxes.
They are ready to splice and already contain splice cassettes, pigtails separated according to IEC 60304 and the associated couplings.

Productadvantages :

Splice boxes are mainly installed in the network cabinet in order to bundle the fiber optic cables converging there - comparable to a patch panel for installation cables made of copper.
In the network cabinet, the signal from the fiber optic cable can be patched to switches, media converters, routers, modems, servers, SFP modules or FTTH / FTTB house entry sockets using patch cables.

Features
High uniformity and reliability
Wide operating wavelength 1260~1650nm
Low insertion and return loss
Built with Corning G.657 Grade A optical
Low Polarization Dependent Loss(PDL)
Operating temperature -40°C to 85°C

Applications
FTTH deployments
CATV networks
Access/PON distributions
LAN,WAN,Metro

Certification and Compliance
GR-1209-CORE Requirements for Passive Optical Components.
GR-1221-CORE Reliability Assurance Requiremnts for Passive Optical Components.
GR-326-CORE   Requirements for Single Mode Optical Connectors and Jumpers Assemblies.
TIA-604              Fiber Optic Connector Intermateability Standard.
ROHS                 Directive on Restriction of Hazardous Substances

Regulatory Approvals

● Telcordia GR-1209-CORE and GR-1221-CORE

● RoHS compliance

1xN/2xN PLC Splitters (without connects)

Parameter	1x4	1x8	1x16	1x32	1x64	2x4	2x8	2x16	2x32
Operating wavelength (nm)	1260~1650
Port wavelength range (nm)	1310±20; 1490±10; 1550±20
Insertion loss @ 1310 nm/1550 nm	7.1	10.5	13.6	16.8	20.5	7.4	10.8	14.5	17.5
Uniformity (dB)	0.5	0.8	1	1.2	1.8	1.2	1.5	1.8	2
PDL @ 1310/1550 nm (dB)	≤0.3
Return loss @ 1310/1550 nm (dB)	≤55
Input power (mW)	250 max
Operating temperature (℃)	-40~+85℃
Storage Temperature (℃)	-40~+85℃
Fiber Type	Corning G657A1

FO splice box, 1U, equipped, 1x32 Splice cassette, colored pigtails, couplings

FO splice box, 1U, equipped, 1x32 Splice cassette, colored pigtails, couplings Images
