0.5M FC - LC 12 Cores Armored Fiber Optic Pigtail Connector , Lc Pigtail Single Mode

Product Categories
Wuhan Geehe Optical Communication Co.,ltd
Contact Now

0.5M FC - LC 12 Cores Armored Fiber Optic Pigtail Connector , Lc Pigtail Single Mode

  • 1
  • 2

Brand Name : Geehe, ODM&OEM

Model Number : GH-LC 009

Certification : Telocordia/ IEC standards,ISO9001,14001

Place of Origin : Wuhan,Hubei

MOQ : 20 pcs

Price : Customerized

Payment Terms : T/T, L/C, Western Union,Cash

Supply Ability : 5,000 pcs/ day

Delivery Time : 5-7 Working Days

Packaging Details : Plastic box per pc with Pressure defense sponge, thick outer carton

Model Type : Fiber Patch Cord

Cable Diameter : 0.9mm, 2.0mm, 3.0mm Optional

Fiber Type : G652D or G657A

Connector Types : LC, SC, FC, ST connector optional

Ferrule End Face : APC or UPC

Jacket : PVC/LSZH

Fiber Counts : singlemode

Application : FTTH FTTB FTTX Network

Cable Length : 1.5m or customized

Contact Now

Competitive Capacity 0.5M FC-LC 12 Cores Armored Optical Fiber Optic Patch Pigtails





Brief Description:





Geehe fibre optic patch cords are one of the most commonly used components of the fibre optic network.



Patch cords may be broadly classified as per fibre type / count & connector type / count. Further sub-classification may be on basis of usage (indoor / outdoor / harsh environment certified), cable ( diameter 0.9 / 2.0 / 3.0 / 4.8 / 8.2 mm), armouring & finally customized cable assemblies

Some common connector types are detailed below:



SC connectors are commonly used patch cords due to good durability and low cost. The push pull design of the connectors is ideal for limited space requirement.





Features:



  1.  Plastic moulded rectangular body
  2.  Low cost compact design
  3.  Available in both Singlemode and Multimode type
  4.  Accurate alignment through ceramic ferrule
  5.  Stable against mechanical or environmental shock
  6.  Low insertion loss and excellent back reflection
  7.  Meets Telocordia/ IEC standards

Application:





    Optical access network



    Optical-fiber CATV



    A local area network(LAN)



    Test Equipment











Specification:



Specification
Parameter Unit Index
End-Face Type   PC UPC APC
IL dB SM: ≤0.3；MM ≤0.1
Repeatability dB ≤0.1
Interchangeability dB ≤0.2
RL SM dB ≥50 ≥50 ≥50
MM dB ≥36(Exclusive APC Connector)
Mating Times   ＞1000
Operating Temperature ℃ -40~ +80







Ordering Information:





OFC -X -XX -XX -XX -X -X
  S: Simplex
D: Duplex		 LA:FC/APC LC:FC/UPC LP:FC/PC LA:FC/APC LC:FC/UPC LP:FC/PC 09:0.9mm 20:2.0mm 30:3.0mm 0:G652D 1:G657A 2:50/125 3:62.5/125 4:others 0.5:0.5m
1.0:1.5m
10:10.0m
Fiber Mode Connector Type Conector Type Cable Diameter Fibe Type Fibe Length









Product Package





0.5M FC - LC 12 Cores Armored Fiber Optic Pigtail Connector , Lc Pigtail Single Mode








Product Tags:

single mode pigtail



plastic optical fiber cable


Buy cheap 0.5M FC - LC 12 Cores Armored Fiber Optic Pigtail Connector , Lc Pigtail Single Mode product

0.5M FC - LC 12 Cores Armored Fiber Optic Pigtail Connector , Lc Pigtail Single Mode Images
